www.analogway.com
99
USER MANUAL
APPENDICES
Appendix A. RC400T
The RC400T event controller will be supported by the Midra™ 4K in a future version.
Appendix B. Use the Shot Box² and Control Box² with Midra™ 4K
Midra™ 4K units are also compatible with the Analog Way Shot Box² (SB80-2) and Control Box² (SB124T-2).
Analog Way Shot Box² and Control Box² can be used to recall Memories and trigger transitions.
Shot Box² Control Box²
To use these controllers:
1. Connect the controller directly to the Midra™ 4K unit via USB ports.
2. On the unit front panel, go to Control > Controller:
a. Go to Status to check the detected Controllers.
b. Enable Identify to display ID on the controller (1 to 4).
3. Select the controller to open its settings:
Controller setting Description
Enable
Enable or disable the controller
Backlight
Set the keyboard brightness (in %)
Mode*
Choose to recall Screen Memories or Master Memories
Screen*
Choose the Screen
Destination*
Choose to interact with Program or Preview
Autoscale
Enable to rescale Memory to applied Screen canvas size
Take on load
Enable to automatically trigger the transition when loading a Memory on Preview
Reset
Reset the controller configuration
*only available with the ShotBox².
4. Use the keys of the controller to recall Memories and trigger transitions.
