Table 1.1.2.1-1: LTE Measurement Software Specifications (MX882112C/13C) (2/3)
Measurement Item
Specifications
Occupied Bandwidth
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
For frequencies below 500 MHz, only the following
range meets the specifications:
452.5 to 457.5 MHz (LTE OperatingBand31)
Input level –10 to +35 dBm (Main1/2)
Channel bandwidth 1.4 MHz, 3 MHz, 5 MHz
(452.5 MHz ≤ UL frequency ≤ 457.5 MHz)
1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz,
20 MHz (500 MHz ≤ UL frequency)
Adjacent Channel
Leakage Power
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
For frequencies below 500 MHz, only the following
range meets the specifications:
452.5 to 457.5 MHz (LTE OperatingBand31)
Input level –10 to +35 dBm (Main1/2)
Measurement point E-UTRA ACLR1
UTRA ACLR1
UTRA ACLR2
Measurement range ≥ 45 dB (E-UTRA ACLR1)
≥ 50 dB (UTRA ACLR1)
≥ 55 dB (UTRA ACLR2)
Channel bandwidth 1.4 MHz, 3 MHz, 5 MHz
(452.5 MHz ≤ UL frequency ≤ 457.5 MHz)
1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz
20 MHz (500 MHz ≤ UL frequency)
Spectrum Emission
Mask
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
For frequencies below 500 MHz, only the following
range meets the specifications:
452.5 to 457.5 MHz (LTE OperatingBand31)
Input level –10 to +35 dBm (Main1/2)
Channel bandwidth 1.4 MHz, 3 MHz, 5 MHz
(452.5 MHz ≤ UL frequency ≤ 457.5 MHz)
1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz,
20 MHz (500 MHz ≤ UL frequency)
