RX Measurements for MT8821C UL CA 2CCs 3.7.
The MT8821C can measure the UL uplink throughput for the Total, PCC, and SCC–1 for UL CA,and display the
measurement results on Phone1.
Restrictions 3.7.1.
There are some restrictions as follows when SCC UL Throughput Measurement is enabled.
 Phone 2 cannot be used.
 SCC–1 UL Throughput and TX cannot be measured simultaneously.
 Set all measurement items except throughput to OFF.
Required options 3.7.2.
option
name
units
remarks
MT8821C–008
LTE Measurement Hardware
2
for SCC UL Throughput Measurement
MT8821C–012
Parallel Phone Measurement Hardware
1
for SCC UL Throughput Measurement
MT8821C–025
2
nd
RF for Phone1
1
for DL 2CA / UL 2CA
MT8821C–026
3
rd
RF for Phone1
1
for DL 3CA / UL 2CA
MT8821C–027
4
th
RF for Phone1
for DL 4CA / UL 2CA
MT8821C–028
2
nd
RF for Phone2
1
for DL 2CA MIMO / UL 2CA
MT8821C–029
3
rd
RF for Phone2
1
for DL 3CA MIMO / UL 2CA
MT8821C–030
4
th
RF for Phone2
for DL 4CA MIMO / UL 2CA
MX88211xC
LTE FDD or TDD Measurement Software
1
MX88211xC–021
LTE–Advanced FDD or TDD DL CA
Measurement Software
1
for DL 2CA
MX88211xC–022
LTE–Advanced FDD or TDD UL CA
Measurement Software
1
for UL 2CA
MX88211xC–031
LTE–Advanced FDD or TDD DL 3CA
Measurement Software
1
for DL 3CA
MX88211xC–041
LTE–Advanced FDD or TDD DL 4CA
Measurement Software
1
for DL 4CA
