Anritsu MT8820C - Bandwidth Handover

66
Bandwidth Handover 2.3.7.
For SCC-2, the following steps are added to the procedure in Chapter 2.2.7.
This chapter describes an example to set parameters in the following table.
Parameter
Setting Value
Channel Bandwidth
PCC
20 MHz
SCC-1
15 MHz
SCC-2
10 MHz
2.3.7.1. MT8820C
<Changing SCC-2 Bandwidth>
1. [PCC] Execute BANDWIDTH_SCC2 10MHZ to set DL Carrier aggregation SCC-2 - Channel Bandwidth to 10
MHz.
2. [SCC-2] Execute BANDWIDTH 10MHZ to set Channel Bandwidth to 10 MHz.
2.3.7.2. MT8821C
<Changing SCC-2 Bandwidth>
1. Execute BANDWIDTH_SCC2 10MHZ to set Common Parameter - SCC-2 - Channel Bandwidth to 10 MHz.
2. Execute CALLSTATIC? to confirm the call processing stationary status is 6 (= Connected).
