Anritsu MT8820C - Client PC Connection and Setting

183
Figure 5.1.2.2.2-2 Internet Protocol Version 6 (TCP/IPv6) Properties Screen (Windows 7)
3. Select [Use following IPv6 address] and set [IPv6 address] and [Subnet prefix length] as described below.
The IPv6 address set by this procedure matches the IP address set at [IPV6 Server IP Address ] of the
MT8821C.
To check [IPV6 Server IP Address ] of the MT8821C, refer to chapter 5.1.2.2.1
 IPv6 address: 2001::2
 Subnet prefix length: 64
NOTE:
 Places in the address with contiguous 0s are abbreviated as::. For example, IPv6 Server IP Address
2001:0000:0000:0000:0000:0000:0000:0002 is abbreviated to 2001::2.
4. Click [OK] and close the properties screen for Internet Protocol Version 6 (TCP/IPv6).
Client PC Connection and Setting 5.1.3.
The client PC connection and setting depend on the mobile terminal. Set according to the connection method used.
