Application Server Connection and Setting 5.2.2.
5.2.2.1. Using External Application Server for MT8820C
With the MT8820C powered-down (Off), use the crossover Ethernet cable to connect the 1000Base-TX port on the
rear panel of the MT8820C to the application server.
When Phone1 is used as PCC and Phone2 is used as SCC-1 for IP data verification for 2DL CA SISO, connect the
1000Base-T1 port on the MT8820C rear panel to the Application Server PC1, and connect the 1000Base-T2 port on
the MT8820C rear panel to the Application Server PC2, respectively.
When using two MT8820Cs for IP data verification for 2DL CA 2x2 MIMO IP, connect the 1000Base-T1 port on the
rear panel of the MT8820C functioning as PCC to the Application Server PC1, and connect the 1000Base-T1 port on
the rear panel of the MT8820C working as SCC-1 to the Application Server PC2, respectively. For details of the
connection diagram, refer to Figure 5.2.1.1-1 or Figure 5.2.1.1-2 in Chapter 5.2.1.
Set the following IP addresses at each of the Application Servers (PC1/2). To set the IP addresses, refer to Chapter
5.1.2.
5.2.2.2. Using External Application Server for MT8821C
With the MT8821C powered-down (Off), use a crossover Ethernet cable to connect the 1000Base-TX port on the
rear panel of the MT8821C to the application server.
Connect the 1000Base-T1 port on the MT8821C rear panel to the Application Server PC1. For details of the
connection diagram, refer to Figure 5.2.1.2-1 or Figure 5.2.1.2-2 in Chapter 5.2.1.
Set the following IP addresses at each of the Application Servers (PC1/2). To set the IP addresses, refer to Chapter
5.1.2.
