62
Initial Condition Setting
2.3.3.
The initial conditions must be set before measurement.
An example of the following settings is shown below.
2.3.3.1. MT8820C
2.3.3.1.1. Setting Example 1 (FDD)
1. [PCC/SCC] Execute PRESET to set the default parameters.
2. [PCC] Execute CHCODING RMC_DL_CA_PCC to set Channel Coding to RMC (DL CA - PCC).
3. [SCC-1] Execute CHCODING RMC_DL_CA_SCC to set Channel Coding to RMC (DL CA - SCC).
4. [SCC-2] Execute CHCODING RMC_DL_CA_SCC to set Channel Coding to RMC (DL CA - SCC).
5. [PCC/SCC] Execute DLSCC 2 to set the number of SCC to 2.
6. [PCC] Execute CALLPROC ON to set Call Processing to On.
7. [PCC] Execute DLCHAN 300 to set UL Channel and DL Channel to 18300 and 300, respectively.
8. [PCC] Execute DLCHAN_SCC1 2525 to set DL Carrier aggregation SCC-1 - DL Channel to 2525.
9. [PCC] Execute DLCHAN_SCC2 4450 to set DL Carrier aggregation SCC-2 - DL Channel to 4450.
10. [PCC] Execute BANDWIDTH 10MHZ to set Channel Bandwidth to 10 MHz.
11. [PCC] Execute BANDWIDTH_SCC1 20MHZ to set DL Carrier aggregation SCC-1 - Channel Bandwidth to 20
MHz.
12. [PCC] Execute BANDWIDTH_SCC2 10MHZ to set DL Carrier aggregation SCC-2 - Channel Bandwidth to 10
MHz.
13. [SCC-1] Execute CALLPROC OFF to set Call Processing to Off.
14. [SCC-1] Execute ULCHAN_PCC 18300 to set DL Carrier aggregation PCC - UL Channel to 18300.
15. [SCC-1] Execute DLCHAN 2525 to set DL Channel to 2525.
16. [SCC-1] Execute BANDWIDTH_PCC 10MHZ to set DL Carrier aggregation PCC - Channel Bandwidth to 10
MHz.
17. [SCC-1] Execute BANDWIDTH 20MHZ to set Channel Bandwidth to 20 MHz.
18. [SCC-2] Execute CALLPROC OFF to set Call Processing to Off.
19. [SCC-2] Execute ULCHAN_PCC 18300 to set DL Carrier aggregation PCC - UL Channel to 18300.
20. [SCC-2] Execute DLCHAN 4450 to set DL Channel to 4450.
21. [SCC-2] Execute BANDWIDTH_PCC 10MHZ to set DL Carrier aggregation PCC - Channel Bandwidth to 10
MHz.
22. [SCC-2] Execute BANDWIDTH 10MHZ to set Channel Bandwidth to 10 MHz.
