Initial Condition Settings 5.3.4.
The following settings are an example of the peak data rate in UE Category 9/11.
[Example of test conditions]
Serv. Cell
Condition
Value
PCC
Operation Band
1
DL Channel
300
UL Channel
18300
Bandwidth
20 MHz
Transmission Mode
(Antenna Configuration)
Transmission Mode3
(2x2 MIMO (Open Loop))
UE Category
When 3DL CA : 9
When 4DL CA : 11
Output Level (Total)
–35.0 dBm
DL Number of RB
100
DL MCS Index
All 28
CFI
1
UL Number of RB
100
UL MCS Index
23
SCC–1
Operation Band
1
DL Channel
498
UL Channel
-
Bandwidth
20 MHz
Output Level (Total)
–35.0 dBm
DL Number of RB
100
DL MCS Index
All 28
CFI
1
SCC–2
Operation Band
3
DL Channel
1575
UL Channel
-
Bandwidth
20 MHz
Output Level(Total)
–35.0 dBm
DL Number of RB
100
DL MCS Index
All 28
CFI
1
SCC-3
Operation Band
3
DL Channel
1773
UL Channel
-
Bandwidth
20 MHz
Output Level(Total)
–35.0 dBm
DL Number of RB
100
DL MCS Index
All 28
CFI
1
