Initial Condition Setting 2.2.3.
The initial conditions must be set before measurement.
A setting example for UL/DL Channel at each condition is shown in the following table.
Component
Carrier
Channel
Intra-Band (FDD)
Inter-Band (FDD)
Intra-Band (TDD)
Inter-Band (TDD)
PCC
UL Channel
18200 (Band1)
18200 (Band1)
38000 (Band38)
38000 (Band38)
DL Channel
200 (Band1)
200 (Band1)
38000 (Band38)
38000 (Band38)
Bandwidth
20MHz
10MHz
10MHz
10MHz
SCC-1
UL Channel
18398 (Band1)
20525 (Band5)
-
39150 (Band40)
DL Channel
398 (Band1)
2525 (Band5)
38099 (Band38)
39150 (Band40)
Bandwidth
20MHz
10MHz
10MHz
10MHz
NOTE 1: UL CA Measurement requires UL Channel setting.
NOTE 2: For MT8820C, Intra-Band Contiguous on UL CA is NOT supported.
