MT8821C 1.1.2.
1.1.2.1. MX882112C/13C (Call Processing)
Table 1.1.2.1-1 LTE Measurement Software Specifications (MX882112C/13C) (1/3)
Measurement Item
Specifications
Electrical
Typical values (typ.) are only for reference and are not guaranteed.
Frequency/Modulation
measurement
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
For frequencies below 500 MHz, only the following
range meets the specifications:
452.5 to 457.5 MHz (LTE OperatingBand31)
Input level –40 to +35 dBm (Main1/2)
Carrier frequency
accuracy ±(Set frequency × Reference oscillator accuracy +15 Hz)
Modulation accuracy
Residual vector error ≤ 2.5% (400 MHz ≤ Freq. ≤ 3800 MHz)
(When measurement count is 20)
≤ 3.5% (3800 MHz < Freq. ≤ 5000 MHz)
(When measurement count is 20)
In-band Emissions ≤–40 dB
(≥–10 dBm, Allocated RB ≤ 18)
Measurement object PUSCH, PRACH, PUCCH
Amplitude
Measurement
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
For frequencies below 500 MHz, only the following
range meets the specifications:
452.5 to 457.5 MHz (LTE OperatingBand31)
Input level –60 to +35 dBm (Main1/2)
Measurement accuracy ±0.5 dB (–20 to +35 dBm)
typ. ±0.3 dB (–20 to +35 dBm)
±0.7 dB (–50 to –20 dBm)
±0.9 dB (–60 to –50 dBm)
400 MHz ≤ Freq. ≤ 3800 MHz
10° to 40°C after calibration
±0.7 dB (–20 to +35 dBm)
±0.9 dB (–50 to –20 dBm)
±1.1 dB (–60 to –50 dBm)
3800 MHz <freq.≤ 5000 MHz
20° to 30°C after calibration
Linearity ±0.2 dB (–40 to 0 dB, ≥–50 dBm)
±0.4 dB (–40 to 0 dB, ≥–60 dBm)
400 to 5000 MHz
Measurement object PUSCH, PRACH, PUCCH
