Anritsu MT8820C - Annex A: ARB Waveform List; A.1. ARB Waveform Installer Version: Q007; A.2. ARB Waveform Installer Version: Q008

258
Annex A: ARB Waveform List
A.1. ARB Waveform Installer Version: Q007
Package1: LTE DL 10 MHz
Note1: TDD Uplink Downlink Configuration = 1, Special Subframe Configuration = 4
Note2: C-RNTI = AAAA (hex)
A.2. ARB Waveform Installer Version: Q008
Package1: LTE DL QPSK 1.4 to 20 MHz
Note1: C-RNTI = AAAA (hex)
No. Pattern Name
Channel
Bandwidth
UL
Number of RB
UL
Start RB
UL
Modulation
DL
Number of RB
DL
Start RB
DL
Modulation
Power
Control
Frame
Structure
0 UL R50 S0 QPSK UP 10 50 0 QPSK 50 0 QPSK All up FDD
1 UL R12 S0 QPSK UP 10 12 0 QPSK 50 0 QPSK All up FDD
2 UL R12 S38 QPSK UP 10 12 38 QPSK 50 0 QPSK All up FDD
3 UL R50 S0 16QAM UP 10 50 0 16QAM 50 0 QPSK All up FDD
4 UL R12 S38 16QAM UP 10 12 38 16QAM 50 0 QPSK All up FDD
5 UL R12 S0 16QAM UP 10 12 0 16QAM 50 0 QPSK All up FDD
6 UL R20 S0 QPSK UP 10 20 0 QPSK 50 0 QPSK All up FDD
7 void - - - - - - - - -
8 void - - - - - - - - -
9 void - - - - - - - - -
10 void - - - - - - - - -
11 void - - - - - - - - -
12 TDD UL R50 S0 QPSK UP 10 50 0 QPSK 50 0 QPSK All up TDD
13 TDD UL R12 S0 QPSK UP 10 12 0 QPSK 50 0 QPSK All up TDD
14 TDD UL R12 S38 QPSK UP 10 12 38 QPSK 50 0 QPSK All up TDD
15 TDD UL R50 S0 16QAM UP 10 50 0 16QAM 50 0 QPSK All up TDD
16 TDD UL R12 S38 16QAM UP 10 12 38 16QAM 50 0 QPSK All up TDD
17 TDD UL R12 S0 16QAM UP 10 12 0 16QAM 50 0 QPSK All up TDD
18 TDD UL R20 S0 QPSK UP 10 20 0 QPSK 50 0 QPSK All up TDD
19 void - - - - - - - - -
20 void - - - - - - - - -
21 void - - - - - - - - -
22 void - - - - - - - - -
23 void - - - - - - - - -
No. Pattern Name
Channel
Bandwidth
UL
Number of RB
UL
Start RB
UL
Modulation
DL
Number of RB
DL
Start RB
DL
Modulation
Power
Control
Frame
Structure
0 FDD 1.4MHz QPSK 1.4 6 0 QPSK 6 0 QPSK All up FDD
1 FDD 3MHz QPSK 3 15 0 QPSK 15 0 QPSK All up FDD
2 FDD 5MHz QPSK 5 25 0 QPSK 25 0 QPSK All up FDD
3 FDD 10MHz QPSK 10 50 0 QPSK 50 0 QPSK All up FDD
4 FDD 15MHz QPSK 15 75 0 QPSK 75 0 QPSK All up FDD
5 FDD 20MHz QPSK 20 100 0 QPSK 100 0 QPSK All up FDD
6 void - - - - - - - - -
7 void - - - - - - - - -
8 void - - - - - - - - -
9 void - - - - - - - - -
10 void - - - - - - - - -
11 void - - - - - - - - -
12 TDD 1.4MHz QPSK 1.4 6 0 QPSK 6 0 QPSK All up TDD
13 TDD 3MHz QPSK 3 15 0 QPSK 15 0 QPSK All up TDD
14 TDD 5MHz QPSK 5 25 0 QPSK 25 0 QPSK All up TDD
15 TDD 10MHz QPSK 10 50 0 QPSK 50 0 QPSK All up TDD
16 TDD 15MHz QPSK 15 75 0 QPSK 75 0 QPSK All up TDD
17 TDD 20MHz QPSK 20 100 0 QPSK 100 0 QPSK All up TDD
18 void - - - - - - - - -
19 void - - - - - - - - -
20 void - - - - - - - - -
21 void - - - - - - - - -
22 void - - - - - - - - -
23 void - - - - - - - - -
