Anritsu MT8820C - Page 259

259
Package2: LTE DL 64QAM 1.4 to 20 MHz
Note1: TDD Uplink Downlink Configuration = 1, Special Subframe Configuration = 4
Note2: C-RNTI = AAAA (hex)
No. Pattern Name
Channel
Bandwidth
UL
Number of RB
UL
Start RB
UL
Modulation
DL
Number of RB
DL
Start RB
DL
Modulation
Power
Control
Frame
Structure
0 FDD 1.4MHz 64QAM 1.4 6 0 QPSK 6 0 64QAM All up FDD
1 FDD 3MHz 64QAM 3 15 0 QPSK 15 0 64QAM All up FDD
2 FDD 5MHz 64QAM 5 25 0 QPSK 25 0 64QAM All up FDD
3 FDD 10MHz 64QAM 10 50 0 QPSK 50 0 64QAM All up FDD
4 FDD 15MHz 64QAM 15 75 0 QPSK 75 0 64QAM All up FDD
5 FDD 20MHz 64QAM 20 100 0 QPSK 100 0 64QAM All up FDD
6 void - - - - - - - - -
7 void - - - - - - - - -
8 void - - - - - - - - -
9 void - - - - - - - - -
10 void - - - - - - - - -
11 void - - - - - - - - -
12 TDD 1.4MHz 64QAM 1.4 6 0 QPSK 6 0 64QAM All up TDD
13 TDD 3MHz 64QAM 3 15 0 QPSK 15 0 64QAM All up TDD
14 TDD 5MHz 64QAM 5 25 0 QPSK 25 0 64QAM All up TDD
15 TDD 10MHz 64QAM 10 50 0 QPSK 50 0 64QAM All up TDD
16 TDD 15MHz 64QAM 15 75 0 QPSK 75 0 64QAM All up TDD
17 TDD 20MHz 64QAM 20 100 0 QPSK 100 0 64QAM All up TDD
18 void - - - - - - - - -
19 void - - - - - - - - -
20 void - - - - - - - - -
21 void - - - - - - - - -
22 void - - - - - - - - -
23 void - - - - - - - - -
