Table 3.9-4: Remote Commands List Limiting Pass/Fail Judgment (4/6)
3GPP Test Item
No.
Channel
Bandwidth
(MHz)
Remote Command
6.5.1 Frequency Error
44
-----
TP_FERR_PPM
TP_FERR_HZ
6.5.1A.1 Frequency Error for CA (intra-band
contiguous DL CA and UL CA)
44
-----
TP_FERR_PPM
TP_FERR_HZ
6.5.2.1 Error Vector Magnitude (EVM) - PUSCH
6.5.2.1A PUSCH-EVM with exclusion period
5, 6,
12, 13
41
-----
TP_EVM_QPSK
TP_RSEVM_QPSK
7, 8,
14, 15
42
TP_EVM_16QAM
TP_RSEVM_16QAM
6.5.2.1 Error Vector Magnitude (EVM) - PUCCH
20, 23
-----
TP_EVM_PUCCH
6.5.2.1 Error Vector Magnitude (EVM) - PRACH
2, 3
-----
TP_EVM_PRACH
6.5.2.2 Carrier Leakage
10
-----
TP_CARRLEAK_0DBM
11
TP_CARRLEAK_M30DBM
12
TP_CARRLEAK_M40DBM
6.5.2.3 In-band Emissions
for non allocated RB
- PUSCH/PUCCH
General
10, 11,
12, 21,
22, 23
-----
TP_INBANDE_GEN_A
TP_INBANDE_GEN_B
TP_INBANDE_GEN_C
TP_INBANDE_GEN_D
IQ Image
TP_INBANDE_IMG
Carrier Leakage
10, 21
TP_INBANDE_LEAK_0DBM
11, 22
TP_INBANDE_LEAK_M30DBM
12, 23
TP_INBANDE_LEAK_M40DBM
6.5.2.4 EVM equalizer spectrum flatness
6
-----
TP_SPECFLAT1_PP
TP_SPECFLAT1_RD
TP_SPECFLAT2_PP
TP_SPECFLAT2_RD
6.5.2A.1.1 Error Vector Magnitude (EVM) for A
(intra-band contiguous DL CA and UL CA)
5, 6,
12, 13
-----
TP_EVM_QPSK limit, PCC *
1
TP_RSEVM_QPSK limit, PCC *
1
TP_EVM_QPSK limit, SCC1 *
1
TP_RSEVM_QPSK limit, SCC1 *
1
7, 8,
14, 15
TP_EVM_16QAM limit, PCC *
1
TP_RSEVM_16QAM limit, PCC *
1
TP_EVM_16QAM limit, SCC1 *
1
TP_RSEVM_16QAM limit, SCC1 *
1
6.5.2A.2.1 Carrier leakage for CA (intra-band contiguous DL
CA and UL CA)
10
-----
TP_CARRLEAK_0DBM
11
TP_CARRLEAK_M30DBM
12
TP_CARRLEAK_M40DBM
