236
6.2.1.2. UTRAN Case
for FDD cells: Srxlev > 0 AND Squal > 0
for TDD cells: Srxlev > 0
Srxlev = Q
rxlevmeas
- (Q
rxlevmin
+ Q
rxlevminoffset
) - Pcompensation
Squal = Q
qualmeas
- (Q
qualmin
+ Q
qualminoffset
)
Cell Selection quality value (dB)
Applicable only to FDD cells
Cell Selection RX level value (dB)
Measured cell quality value. Quality of received signal expressed in CPICH Ec/N0
(dB) for FDD cells. CPICH Ec/N0 is averaged. Applicable only to FDD cells.
Measured cell RX level value. This is received signal, CPICH RSCP for FDD cells (dBm)
and P-CCPCH RSCP for TDD cells (dBm).
Minimum required quality level in cell (dB). Applicable only to FDD cells.
Offset to signalled Qqualmin taken into account in Squal evaluation as result of
periodic search for higher-priority PLMN while camped normally in VPLMN.
Minimum required RX level in cell (dBm).
Offset to signalled Qrxlevmin taken into account in Srxlev evaluation as result of
periodic search for higher-priority PLMN while camped normally in VPLMN.
max(UE_TXPWR_MAX_RACH - P_MAX, 0) (dB)
Maximum TX power level UE may use when accessing cell on RACH (read in system
information) (dBm).
Maximum RF output power of UE (dBm).
- Refer to the Inter-RAT Cell Reselection criteria (6.2.3) for comparison with the MT8821C settings.
- These criteria are defined in 3GPP TS25.304 5.2.3.1.
6.2.1.3. GSM Case
Path loss criterion parameter (dB)
Running average of received signal level
Minimum received signal level at MS required for access to system (dBm).
Max MS_TXPWR_MAX_CCH - P, 0) (dB)
Maximum TX power level MS may use when accessing system until otherwise
commanded.
Maximum RF output power of MS.
- Refer to the Inter-RAT Cell Reselection criteria (6.2.3) for comparison with the MT8821C settings.
- These criteria are defined in 3GPP TS45.008 6.4.
