Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Transmission Argo Service Manual
TR-14
TR-26
TR-27
Some transmissions may have (2) Shims instead of (1). In rare cases there may be none
used. In any case, when reassembling, use the same amount as were used originally.
18. Using a soft faced hammer, tap the Input Shaft out of the Housing. Photo TR-28
19. Place the Housing in the assembly fixture to remove all Bearings, Retaining Rings,
Seals and the Plug Plate.
20. Remove the old Cover Gasket. Photo TR-29
21. Knock the outer Bearing from the Housing using a hammer and drift punch. Tap
around the perimeter of the Bearing through the backside of the housing to ensure
that it will not bind . Photo TR-30
TR-28 TR-29
22 Knock out the Housing Plug Plate. Photo TR-31
