Argo Service Manual Transmission
TR-51
TR-194
67. Rotate the Transmission and secure the opposite end of the Reverse Idler Pin with a
2
nd
Retaining Ring. Photo TR-195
68. Once the Retaining Ring has been secured to the Cover Side, use a hammer and tap
the pin back in the opposite direction to seat the Retaining Ring to the Cover. Photo
TR-196
TR-195
TR-196
TR-197
69. Wipe off the Input Shaft with a lint free rag to remove any oil and debris and insert it
into the Input Shaft opening. Use a soft faced mallet to seat the Input Shaft to the
Bearing on the Cover Side. Photo TR-197, 198 & 199
TR-198 TR-199
