Transmission Argo Service Manual
TR-52
70. Rotate the Input Shaft to check that it turns freely. Photo TR-200
71. Place the Input Bearing over the Input Shaft and seat it with a soft faced mallet and
installation tool. Photo TR-201, 202 & 203
TR-200 TR-201
TR-202 TR-203
72. Place (1) Shim Washer on top of the previously installed Bearing. Photo TR-204
A transmission may utilize either 1 or 2 shims here. When reassembling, always
install the original quantity.
TR-204
TR-205
73. Install and seat the Retaining Ring. Photo TR-205 & 206
