2.8.6 Check Measurement Result Report
Once check measurement has been completed, you can press Print to obtain a printed results
report.
Example
When measurement was interfered with lights from outside of the instrument:
When the check strip was placed out of position and could not be measured:
CHECK Serial No.12345678
2006-01-10 14:10
========================
430[nm] 89.3%
500[nm] 93.1%
565[nm] 88.5%
635[nm] 9.7%
760[nm] 100.0%
Type of measurement
Measurement date and time
Reflectivities
Wavelengths
CHECK
2006-01-10 14:10
========================
Reflection light intensity drift
========================
Error message
CHECK
2006-01-10 14:10
========================
Test strip out-of-position
========================
Error message
