AUTION MAX AX-4030 OPERATING MANUAL
B
1.1.3 Specifications
Specifications
Product AUTION MAX AX-4030
Configuration Instrument, sampler, and accessories
Sample Urine
Reagent AUTION Sticks 9EB
Instrument specifications
Measurement items GLU (Glucose), PRO (Protein), BIL (Bilirubin), URO (Urobilinogen), PH (pH), BLD (Blood),
KET (Ketones), NIT (Nitrite), LEU (Leukocytes), S.G. (Specific gravity), turbidity,
and color tone
Measurement range Test strip: For rank table, see page 1-11.
S.G.: 1.000 to 1.050 (Resolution: 0.001)
Color tone: For color classification diagram, see page 1-9.
Turbidity: Three levels including “clear”, “turbid”, and “excessively turbid”
Measurement method Test strip: Dual-wavelength reflectance measurement (Single wavelength for BLD)
S.G.: Reflection refractometry
Color tone: Light-transmission measurement
Turbidity: Light-scattering measurement
Measurement wavelength 5 LED wavelengths (430, 500, 565, 635, 760 nm)
Sample supply Sampler
Test strip reaction About 60 seconds
Test strip storage Two test strip storage compartments, each of which can contain different test strips
Test strip storage capacity Max. 200 test strips × two storage compartments
Processing speed 225 samples/hour
Sample consumption 0.90 mL
Required sample volume Min. 2.0 mL
Sample container Use the sample tubes that comply with the standards illustrated in “Sample Containers” in
“2.1.4 Sample Containers and Sample Racks” on page 2-7.
Applicable racks ARKRAY racks
Sample loading capacity One-way transportation (default): Max. 50 samples, Loop transportation: Max. 100 samples
Warm-up time Max. 2 minutes
Display Large color liquid crystal display (320 × 240 dots)
Built-in printer 58-mm width thermal printer paper (24 digits)
Memory capacity Normal and STAT measurement: 2500 tests
Control measurement: 200 tests
Check measurement: 50 tests
Trouble list: 100 tests
External output 2 ports (One of these ports can be optionally used as an Ethernet port.)
Communication system RS-232C compliant (Switchable between one-way and two-way)
Transmission speed RS-232C: Selectable from 300, 600, 1200, 2400, 4800, 9600, and 19200 bps
Ethernet: 10BASE-T
Thermal compensation Supported
Operating environment Temperature: 10 - 30°C; Humidity: 20 - 80% RH (Non-condensing)
Measurement environment Temperature: 10 - 30°C; Humidity: 30 - 60% RH (Non-condensing)
Storage environment Temperature: 1 - 30°C; Humidity: 20 - 80% RH (Non-condensing)
Environment during transport Temperature: -13 - 43°C; Humidity: 20 - 80% RH (Non-condensing)
Dimensions 530 (W) × 530 (D) × 530 (H) mm
Weight Instrument: approx. 37 kg; Sampler: approx. 4 kg
Supply voltage (Instrument) 100 - 240 V AC (Max. power line fluctuation of ±10%), 50/60 Hz
Power input Max. 150 VA
Sound pressure level Less than 85 dB
Site location For indoor use only
Altitude 2000 m
Pollution degree 2
Over voltage category
II
Expected life 5 years (According to company data)
