Arkray AUTION MAX AX-4030 - Troubleshooting

AX-4030
5-1
AUTION MAX AX-4030 OPERATING MANUAL
G
Troubleshooting
5.1 When a Warning Occurs ..........................................5-2
5.1.1 From Warning Generation to Remedy .........
5-2
5.1.2 Causes and Remedies .................................
5-3
W001 – W003 ............5-3 W004 – W009 .............5-4
W010 – W011 ............
5-5
5.2 When an Error Occurs .............................................5-6
5.2.1 From Error Generation to Remedy ..............
5-6
5.2.2 Causes and Remedies .................................
5-7
E101 – E104 ..............5-7 E110 – E120 ...............5-8
E130 – E140 ..............
5-9
5.3 When Trouble Occurs ............................................5-10
5.3.1 From Trouble Generation to Remedy ........5-10
5.3.2 Causes and Remedies ...............................5-11
T999, T201 – T203 ... 5-11 T210 – T220 .............5-12
T221 – T222 ............. 5-13 T223 – T240 .............5-14
T241 – T261 ............. 5-15 T270 – T290 .............5-16
5.4 Measurement-Related Messages ..........................5-17
5.4.1 Results-Related Errors (Printed Results
Reports: on the lowest line) .......................5-17
No sample ................ 5-17 Skipped .....................5-17
Reflection light intensity drift ..........................................5-17
Excess reflectivity ...........................................................5-18
Test strip out-of-position .................................................5-18
Abnormal sampling ........................................................5-18
5.4.2 S.G. Measurement-Related Errors
(Printed Results Report: S.G.) ..................5-19
UNDER ....................5-19 OVER .......................5-19
--------- ......................5-19 CAL. ERR .................5-19
5.4.3 Turbidity Measurement-Related Errors
(Printed Results Report: TURB) ................
5-20
CAL. ERR ................. 5-20 ERROR .....................5-20
5.4.4 Messages on the Abnormal Results List ....5-20
Barcode misread ...... 5-20 No sample ................5-20
Measurement error ... 5-21 Abnormal data ..........5-21
Positive sample ........ 5-21
S.G. measurement error ................................................5-21
Turbidity measurement error ..........................................5-21
5.5 If This Happens .......................................................5-22
5.5.1 If the Instrument Does Not Start Up
(Replacing Fuses) .....................................
5-22
Chapter
5
