9. Error Messages
If an error related to measurement or computing occurs, an appropriate message is added at the end
of the results report. For more information, see “5.4.1 Results-Related Errors” on page 5-17.
Messages Descriptions
No sample No sample was detected.
Skipped The sample was not measured.
Reflection light intensity drift The light intensity is drifting.
Excess reflectivity The reflectivity was excessively high.
Test strip out-of-position The test strip was placed out of the correct position.
Abnormal sampling The nozzle could not spot the sample on the test strip.
2.8.3 Abnormal Results List
If incorrect results are obtained, you can manually print an abnormal results list to determine
the cause of the error. This list includes information related to the results that are obtained after
powering-on. For instructions, see “3.5.2 Printing the Abnormal Results List” on page 3-24. For
information on the error messages that can appear in this list, see “5.4.4 Messages on the Abnormal
Results List” on page 5-20.
Example
2.8.4 Error and Trouble List (Automatic Report)
If an error or trouble occurs, the appropriate code is automatically reported on a printout. An error
code consists of an “E” and a 3-digit number and a trouble code, a “T” and a 3-digit number. For
information on the error and trouble codes, see “5.2 When an Error Occurs” on page 5-6 and “5.3
When Trouble Occurs” on page 5-10.
Example
2005-01-11 12:34
E110 001 - 002 - 003
------------------------
2005-01-11 12:40
T120 123 - 456 - 789
Measurement date and time
Error code (“E” and 3-digit number) or
trouble code (“T” and 3-digit number), and
its detailed information (3-digit number)
* The detailed information is to be used by ARKRAY servicemen.
