Arkray AUTION MAX AX-4030 User Manual

AX-4030
2-53
AUTION MAX AX-4030 OPERATING MANUAL
J
7. Specific Gravity (S.G.)
■ Abnormal S.G. mark
Abnormal S.G. results are flagged with an asterisk (*).
(Blank) Normal
*
The GLU and PRO correction is beyond capability (their results are shown as “OVER”).
The S.G. value falls out of the upper or lower thresholds set for the instrument.
■ Errors
If an incorrect S.G. result is obtained, any of the following messages will be added. For more
information, see “5.4.2 S.G. Measurement-Related Errors” on page 5-19.
UNDER The result is lower than the specified range.
OVER The result is higher than the specified range.
-------- Specific gravity was not measured for some reason.
CAL. ERR. S.G. calibration has not been performed yet.
8. Color tone
The color tone of samples is determined from 23 colors, which includes 21 combinations of 7
colors (yellow, orange, brown, red, violet, blue, and green) and 3 intensity levels (light, normal,
dark), colorless, and others.
COLORLESS
YELLOW LIGHT, normal and DARK are indicated for each color.
Example: LIGHT YELLOW, YELLOW, and DARK YELLOW
ORANGE
BROWN
RED
VIOLET
BLUE
GREEN
OTHER
REFERENCE: If the result format is set to [Reflectivity], the color tone results are represented as
[x] and [y].
