AUTION MAX AX-4030 OPERATING MANUAL
F
Before Making Measurements2.1
2.1.1 Flowchart of Operational Procedure
Check the instrument
Press standby switch to power on.
Press standby switch to power off.
Standby screen
Standby screen again
1. Check for used test strips and liquid waste.
2. Check the washing solution and printer paper.
Load test strips
1. Load test strips into the feeders.
Make S.G. calibration
1. Prepare S.G. standard solutions and
measure S.G. standard values.
2. Load standard solutions.
3. Input standard solution values.
4. Start S.G. calibration.
* It is recommended to perform S.G. calibration
once a month.
Control measurement
1. Prepare test strips and check the main
feeder.
2. Prepare controls.
3. Load controls into STAT and control
rack.
4. Load rack into sampler.
5. Set start measurement No.
6. Press START.
7. When completed, take out sample
racks.
Check measurement
1. Clean strip transportation path inside
instrument.
2. Choose Check measurement from
menu.
3. Select feeder number for first check
strip.
4. Load check strip into feeder.
5. Press START to measure strip.
6. Print the first result.
7. Measure second test strip in the same
way.
8. Print the second result.
9. Interpret the results.
Prepare samples
1. Label sample tubes with barcodes,
if needed.
2. Pour samples into tubes.
3. Load samples into sample racks.
4. Load sample racks into sampler.
Normal measurement
1. Check the type of test strips and main
feeder.
2. Set the measurement start No.
3. Press START.
4. After completion, take out samples.
Daily maintenance
1. Return test strips in the feeders to the bottle.
2. Discard used test strips and clean waste box.
3. Discard liquid waste.
Set parameters
• Set the type of test strips for each feeder.
• Select the main feeder.
• Assign the type of test strips to the item
racks.
• Set the measurement start No.
*Change the measurement No. assignment and
result format as needed.
Port STAT measurement
For single sample
1. Prepare a STAT sample.
2. Place the sample in the STAT port.
3. Press STAT.
4. Set the type of test strips, measurement
No., and ID.
5. Press START.
6. When completed, take out the sample.
Rack STAT measurement
Max. 7 samples
1. Prepare STAT samples.
2. Load the samples into the STAT and
control rack.
• Press STAT to set the type of test strips
and measurement start No.
3. Load the STAT and control rack into the
sampler.
Ready for measurement
2006-01-09 10:00
Measurement start No.
0001
Test strips in feeder 1
1: 9EB
Test strips in feeder 2
2: 9EB
Menu Meas No. Strip S.G. Cal
