AUTION MAX AX-4030 OPERATING MANUAL
B
2.8.2 Printed Results Report
During measurement of urine samples and controls, the instrument prints a results report each
time it obtains a result by analyzing an individual sample or control. See the following figure for
information on what the printed results report includes.
Example
1. Abnormal Mark, Type of Measurement, and Measurement Number
An abnormal mark, the type of measurement and measurement number appear at the beginning of
the results report.
■ Abnormal mark
An abnormal result is flagged with a black circle (●) or question mark (?). The whole first line
appears in reverse video to make it immediately recognizable. The question mark has a higher
priority than the black circle.
● The sample is positive or abnormally colored.
? The instrument is operating abnormally.
Example
Measure No.0001
ID 1234567890-ABCDEFG
2006-01-10 13:41 25
Po.001-01 Strip 9EB(1)
========================
GLU 50 mg/dl
PRO -
BIL -
URO NORMAL
PH 7.0
BLD -
KET -
NIT -
LEU -
TURB 1+
S.G. 1.000
Color Colorless
========================
No sample
========================
1. Abnormal mark, type of measurement, measurement No.
2. ID
3. Measurement date and time, and ambient temperature
4. Rack-port No., type of test strip (feeder No.)
5. Result obtained with a test strip
(abnormal mark, item name, qualitative value,
semiquantitative/reflectivity*)
6. Turbidity (abnormal mark, qualitative value, turbidity value*, error)
7. S.G. (abnormal mark, S.G. value, error)
8. Color tone
9. Error message
* The reflectivity and turbidity value (TURB) are
included when the result format is set to [Reflectivity].
Measure No.0002
ID 1234567890-ABCDEFF
2006-01-10 13:41
