AX-4030
2-51
AUTION MAX AX-4030 OPERATING MANUAL
B
■ Type of measurement
There are 6 types of measurements as listed below.
Measure Normal measurement
Stat Port or rack STAT measurement
Control-L Low-density control measurement
Control-M Middle-density control measurement
Control-H High-density control measurement
Check Check measurement
■ Measurement number
An assigned measurement number, from 0000 to 9999, appears.
2. ID
An ID number appears when the barcode reader reads a barcode from a labeled sample tube. An ID
can contain up to 18 characters, and shorter IDs are preceded by spaces to fill all the 18 digits. For
samples with no ID, 18 hyphens (-) appear instead.
3. Measurement Date and Time, and Ambient Temperature
The date and time when the measurement is carried out and the ambient temperature in centigrade
appear here. The default date format is “year (4 digits) - month (2 digits) - day (2 digits)”.
REFERENCE: The date format can be changed to “day (2 digits) - month (2 digits) - year (4
digits)” or “month (2 digits) - day (2 digits) - year (4 digits)”. To have the parameter settings
changed, contact your distributor.
4. Rack-Port Number, Type of Test Strip, and Feeder Number
The rack-port number identifies where the sample is located. The first 3 digits represent sample
rack count from the beginning of the batch, and the following 2 digits represent the port number on
the sample rack (see also “Rack-port number” in “2.1.3 Measurement Terminology” on page 2-4).
Example: “Po. 004-08” shows the sample is loaded in port 8 of the forth sample rack.
To Next Page
