1-42
AX-4030
AUTION MAX AX-4030 OPERATING MANUAL
1.7.3 Menu Operations and Examples
Basic Operations
■ Function labels and function keys
The lowest line of the screen contains up to four
function labels for activating different functions
depending on the status of the instrument. Each
function label corresponds to the function key (
°
)
just below it. For example, “Press Menu ” refers
to “press the function key below the function label
Menu ”.
Frequently used functions are also assigned to the hardware keys on the operator panel. It is
recommended to learn the functions commonly available through the measurement and setting
operations because the later chapters in this manual do not include detailed descriptions of such
functions.
Function labels Descriptions
Start
This function label appears when the instrument is ready for measurement. Press this
function key to start measurement, or restart the suspended measurement. The
key on the operator panel also works in the same way.
Stop This function label appears while measurement is in progress. Press Stop to
suspend the measurement process. The instrument then shifts to the end process
before going on standby. The
key on the operator panel works in the same way.
Until the end process begins, you can press
Start to resume the suspended
measurement.
Cancel This function label appears on the setup screens. Pressing Cancel aborts all the
settings you made and brings you back to the previous screen.
OK This function label appears when a warning, error, or trouble occurs. Press OK to
clear the problem.
Go back
This function label appears on the menu screens or after the completion of a task. The
instrument displays the previous screen each time
Go back is pressed until finally
reaching the standby screen.
■ Menu screen operations
To select an option from a menu screen, press the
numeric key corresponding to the number of that
option.
To Next Page
