SIP User's Manual 134 Document #: LTRT-65415
MediaPack Series
¾ To configure redirect Tel-to-IP manipulation rules:
1. Open the 'Redirect Number Tel > IP' page (Configuration tab > VoIP menu > GW
and IP to IP submenu > Manipulations submenu > Redirect Number Tel > IP).
Figure 3-83: Redirect Number Tel to IP Page
The figure below shows an example configuration in which the redirect prefix "555" is
manipulated. According to the configured rule, if for example the number 5551234 is
received, after manipulation the device sends the number to IP as 91234.
2. Configure the redirect number Tel to IP rules according to the table below.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, see ''Saving Configuration'' on page 169.
Table 3-22:
Redirect Number Tel to IP Parameters Description
Parameter Description
Source Trunk Group The Hunt Group from where the Tel call is received. To denote any
Hunt Group, leave this field empty.
Note: The value -1 indicates that this field is ignored in the rule.
Source IP Group The IP Group from where the IP-to-IP call originated. Typically, the IP
Group of an incoming INVITE is determined/classified using the ‘IP to
Hunt Group Routing Table'. If not used (i.e., any IP Group), simply
leave the field empty.
Notes:
The value -1 indicates that it is ignored in the rule.
This parameter is applicable only to the IP-to-IP application.
Web/EMS: Destination
Prefix
Destination (called) telephone number prefix. An asterisk (*) represents
any number.
Web/EMS: Redirect Prefix Redirect telephone number prefix. An asterisk (*) represents any
number.
Web: Stripped Digits From
Left
EMS: Remove From Left
Number of digits to remove from the left of the telephone number prefix.
For example, if you enter 3 and the phone number is 5551234, the new
phone number is 1234.
Web: Stripped Digits From
Right
EMS: Remove From Right
Number of digits to remove from the right of the telephone number
prefix. For example, if you enter 3 and the phone number is 5551234,
the new phone number is 5551.
Web/EMS: Prefix to Add The number or string that you want added to the front of the telephone
number. For example, if you enter '9' and the phone number is 1234,
the new number is 91234.
Web/EMS: Suffix to Add The number or string that you want added to the end of the telephone
number. For example, if you enter '00' and the phone number is 1234,
the new number is 123400.
