Version 6.2 75 February 2011
SIP User's Manual 3. Web-Based Management
Parameter Description
IP Address
[SNMPManagerTableIP_x]
IP address of the remote host used as an SNMP Manager.
The device sends SNMP traps to these IP addresses.
Enter the IP address in dotted-decimal notation, e.g.,
108.10.1.255.
Trap Port
[SNMPManagerTrapPort_x]
Defines the port number of the remote SNMP Manager.
The device sends SNMP traps to these ports.
The valid SNMP trap port range is 100 to 4000. The
default port is 162.
Trap Enable
[SNMPManagerTrapSendingEnable_x]
Activates or de-activates the sending of traps to the
corresponding SNMP Manager.
[0] Disable = Sending is disabled.
[1] Enable = Sending is enabled (default).
3.3.1.6.6.3 Configuring SNMP Trusted Managers
The 'SNMP Trusted Managers' page allows you to configure up to five SNMP Trusted
Managers, based on IP addresses. By default, the SNMP agent accepts SNMP Get and
Set requests from any IP address, as long as the correct community string is used in the
request. Security can be enhanced by using Trusted Managers, which is an IP address
from which the SNMP agent accepts and processes SNMP requests.
¾ To configure SNMP Trusted Managers:
1. Open the 'SNMP Trusted Managers' page (Maintenance tab > System menu >
Management submenu > SNMP submenu > SNMP Trusted Managers).
Figure 3-47: SNMP Trusted Managers
2. Select the check box corresponding to the SNMP Trusted Manager that you want to
enable and for whom you want to define an IP address.
3. Define an IP address in dotted-decimal notation.
4. Click the Submit button to apply your changes.
5. To save the changes, see ''Saving Configuration'' on page 169.
