SIP User's Manual 78 Document #: LTRT-65415
MediaPack Series
3.3.2 VoIP Settings
The VoIP menu includes the following main submenus:
Network (see ''Network'' on page 78)
Secu
rity (see ''Security'' on page 89)
Media (se
e ''Media'' on page 98)
Applicatio
ns Enabling (see "Enabling Applications" on page 102)
Control Net
work (see ''Control Network'' on page 103)
SIP Definitions (see ''SIP Definitions'
' on page 110)
Cod
ers And Profiles (see ''Coders and Profiles'' on page 117)
GW an
d IP to IP (see ''GW and IP to IP'' on page 124)
SAS (see "SAS" on page 161)
3.3.2.1 Network
The Network Settings submenu includes the following items:
IP Settings (see ''Configuring IP Interface Settings'' on page 78)
IP Routing Ta
ble (see ''Configuring the IP Routing Table'' on page 82)
QoS Settings (see '
'Configuring QoS Settings'' on page 84)
DNS (se
e ''DNS'' on page 86)
3.3.2.1.1 Configuring IP Interface Settings
The 'Multiple Interface Table' page allows you to configure up to 16 (up to 15 Control/Media
interfaces and a single OAMP interface) logical network interfaces. Each interface can be
defined with its own IP address, unique VLAN ID, arbitrary interface name, default
gateway, and one of the following application types permitted on the interface:
Control - call control signaling traffic (i.e., SIP)
Media - RTP traffic
Operations, Administration, Maintenance and Provisioning (OAMP) - management
(such as Web- and SNMP-based management)
This page also provides VLAN-related parameters for enabling VLANs and defining the
'Native' VLAN ID (i.e., VLAN ID to which incoming, untagged packets are assigned). For
assigning VLAN priorities and Differentiated Services (DiffServ) for the supported Class of
Service (CoS), see "Configuring the QoS Settings" on page 84.
