Table 10-4: QoS Parameters
Parameter Description
Layer-2 Class Of Service (CoS) Parameters (VLAN Tag Priority Field)
Web: Network Priority
EMS: Network Service Class Priority
[VLANNetworkServiceClassPriority]
Defines the VLAN priority (IEEE 802.1p) for Network
Class of Service (CoS) content.
The valid range is 0 to 7. The default value is 7.
Web: Media Premium
EMS: Premium Service Class Media Priority
Priority
[VLANPremiumServiceClassMediaPriority]
Defines the VLAN priority (IEEE 802.1p) for the
Premium CoS content and media traffic.
The valid range is 0 to 7. The default value is 6.
Web: Control Premium Priority
EMS: Premium Service Class Control Priority
[VLANPremiumServiceClassControlPriority]
Defines the VLAN priority (IEEE 802.1p) for the
Premium CoS content and control traffic.
The valid range is 0 to 7. The default value is 6.
Web: Gold Priority
EMS: Gold Service Class Priority
[VlanGoldServiceClassPriority]
Defines the VLAN priority (IEEE 802.1p) for the
Gold CoS content.
The valid range is 0 to 7. The default value is 4.
Web: Bronze Priority
EMS: Bronze Service Class Priority
[VLANBronzeServiceClassPriority]
Defines the VLAN priority (IEEE 802.1p) for the
Bronze CoS content.
The valid range is 0 to 7. The default value is 2.
Layer-3 Class of Service (TOS/DiffServ) Parameters
Web: Network QoS
EMS: Network Service Class Diff Serv
[NetworkServiceClassDiffServ]
Defines the Differentiated Services (DiffServ) value
for Network CoS content.
The valid range is 0 to 63. The default value is 48.
Web: Media Premium QoS
EMS: Premium Service Class Media Diff Serv
[PremiumServiceClassMediaDiffServ]
Defines the DiffServ value for Premium Media CoS
content (only if IPDiffServ is not set in the selected
IP Profile).
The valid range is 0 to 63. The default value is 46.
Note: The value for the Premium Control DiffServ is
determined by the following (according to priority):
IPDiffServ value in the selected IP Profile
(IPProfile parameter).
PremiumServiceClassMediaDiffServ.
Web: Control Premium QoS
EMS: Premium Service Class Control Diff Serv
[PremiumServiceClassControlDiffServ]
Defines the DiffServ value for Premium Control CoS
content (Call Control applications) - only if
ControlIPDiffserv is not set in the selected IP Profile.
The valid range is 0 to 63. The default value is 40.
Notes:
The value for the Premium Control DiffServ is
determined by the following (according to
priority):
9 SiglPDiffserv value in the selected IP Profile
(IPProfile parameter).
9 PremiumServiceClassControlDiffServ.
The same value must be configured for this
parameter and the parameter MLPPDiffServ.
Outgoing calls are tagged according to this
parameter.
Web: Gold QoS
EMS: Gold Service Class Diff Serv
[GoldServiceClassDiffServ]
Defines the DiffServ value for the Gold CoS content
(Streaming applications).
The valid range is 0 to 63. The default value is 26.
