SIP User's Manual 330 Document #: LTRT-65415
MediaPack Series
The corresponding ini file configuration is shown below:
; Interface Table Configuration:
[InterfaceTable]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
InterfaceTable 0 = 6, 10, 192.168.85.14, 16, 192.168.0.1, 1,
myInterface;
[\InterfaceTable]
; Routing Table Configuration:
[ StaticRouteTable ]
FORMAT StaticRouteTable_Index = StaticRouteTable_InterfaceName,
StaticRouteTable_Destination, StaticRouteTable_PrefixLength,
StaticRouteTable_Gateway, StaticRouteTable_Description;
StaticRouteTable 0 = 0, 201.201.0.0, 16, 192.168.0.2, ;
StaticRouteTable 1 = 0, 202.202.0.0, 16, 192.168.0.3, ;
[ \StaticRouteTable ]
Example 2 - Three VoIP Interfaces, One for each Application Exclusively: the Multiple
Interface table is configured with three interfaces, one exclusively for each application type:
one interface for OAMP applications, one for Call Control applications, and one for RTP
Media applications:
Table 9-11: Multiple Interface Table - Example2
Index
Allowed
Applications
Interface
Mode
IP Address
Prefix
Length
Default
Gateway
VLAN
ID
Interface
Name
0 OAMP IPv4
Manual
192.168.85.14 16 0.0.0.0 1 ManagementIF
1 Control IPv4
Manual
200.200.85.14 24 200.200.85.1 200 myControlIF
2 Media IPv4
Manual
211.211.85.14 24 211.211.85.1 211 myMediaIF
VLANs are required. The 'Native' VLAN ID is the same VLAN ID as the Management
interface (Index 0).
One routing rule is required to allow remote management from a host in 176.85.49.0 / 24:
Table 9-12: Routing Table - Example 2
Destination Prefix Length Gateway Interface Metric
176.85.49.0 24 192.168.0.1 0 1
All other parameters are set to their respective default values. The DNS/NTP applications
are left with their default application types.
