AudioCodes MediaPack MP-124 User Manual

SIP User's Manual 188 Document #: LTRT-65415
MediaPack Series
3.5.2.5 Viewing Call Routing Status
The 'Call Routing Status' page provides you with information on the current routing method
used by the device. This information includes the IP address and FQDN (if used) of the
Proxy server with which the device currently operates.
¾ To view the call routing status:
 Open the 'Call Routing Status' page (Status & Diagnostics tab > VoIP Status menu
> Call Routing Status).
Figure 3-119: Call Routing Status Page
Table 3-32: Call Routing Status Parameters
Parameter Description
Call-Routing Method
 Proxy/GK = Proxy server is used to route calls.
 Routing Table = The 'Tel to IP Routing' is used to route calls.
IP Address
 Not Used = Proxy server isn't defined.
 IP address and FQDN (if exists) of the Proxy server with which the
device currently operates.
State
 N/A = Proxy server isn't defined.
 OK = Communication with the Proxy server is in order.
 Fail = No response from any of the defined Proxies.

AudioCodes MediaPack MP-124 Specifications

General

Model	MediaPack MP-124
Category	Gateway
Protocols	SIP, H.323, MGCP
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Fax Support	T.38
Management	SNMP
Security	TLS/SRTP
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25 to 70°C
Humidity	10% to 90%, non-condensing
Analog Ports	24 FXS
