SIP User's Manual 328 Document #: LTRT-65415
MediaPack Series
9.7.3 Setting Up VoIP Networking
9.7.3.1 Using the Web Interface
The Web interface is a convenient user interface for configuring the device's network
configuration.
9.7.3.2 Using the ini File
When configuring the network configuration using the ini File, use a textual presentation of
the Interface and Routing Tables, as well as some other parameters. The following shows
an example of a full network configuration, consisting of all the parameters described in
this section:
; VLAN related parameters:
VlanMode = 0
VlanNativeVlanId = 1
; Routing Table Configuration:
[ StaticRouteTable ]
FORMAT StaticRouteTable_Index = StaticRouteTable_InterfaceName,
StaticRouteTable_Destination, StaticRouteTable_PrefixLength, StaticRouteTable_Gateway,
StaticRouteTable_Description;
StaticRouteTable 0 = 0, 201.201.0.0, 16, 192.168.0.2, ;
StaticRouteTable 1 = 0, 202.202.0.0, 16, 192.168.0.3, ;
[ \StaticRouteTable ]
; Class Of Service parameters:
VlanNetworkServiceClassPriority = 7
VlanPremiumServiceClassMediaPriority = 6
VlanPremiumServiceClassControlPriority = 6
VlanGoldServiceClassPriority = 4
VlanBronzeServiceClassPriority = 2
NetworkServiceClassDiffServ = 48
PremiumServiceClassMediaDiffServ = 46
PremiumServiceClassControlDiffServ = 40
GoldServiceClassDiffServ = 26
BronzeServiceClassDiffServ = 10
; Application Type for applications:
EnableDNSasOAM = 1
EnableNTPasOAM = 1
; Multiple Interface Table Configuration:
[InterfaceTable]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes, InterfaceTable_InterfaceMode,
InterfaceTable_IPAddress, InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
InterfaceTable 0 = 6, 10, 192.168.85.14, 16, 192.168.0.1, 1, myAll;
This ini file shows the following:
A Multiple Interface table with a single interface (192.168.85.14/16, OAMP, Media and
Control applications are allowed) and a default gateway (192.168.0.1).
A Routing table is configured with two routing rules, directing all traffic for subnet
201.201.0.0/16 to 192.168.0.2, and all traffic for subnet 202.202.0.0/16 to 192.168.0.3.
VLANs are disabled; 'Native' VLAN ID is set to 1.
