SIP User's Manual 262 Document #: LTRT-65415
MediaPack Series
8.2.7.7 Message Waiting Indication
The device supports Message Waiting Indication (MWI) according to IETF Internet-Draft
draft-ietf-sipping-mwi-04, including SUBSCRIBE (to MWI server).
Note: For a detailed description on IP voice mail configuration, refer to the IP Voice
Mail CPE Configuration Guide.
The FXS device can accept an MWI NOTIFY message that indicates waiting messages or
that the MWI is cleared. Users are informed of these messages by a stutter dial tone. The
stutter and confirmation tones are defined in the CPT file (refer to the Product Reference
Manual). If the MWI display is configured, the number of waiting messages is also
displayed. If the MWI lamp is configured, the phone’s lamp (on a phone that is equipped
with an MWI lamp) is lit. The device can subscribe to the MWI server per port (usually used
on FXS) or per device (used on FXO).
To configure MWI, use the following parameters:
EnableMWI
MWIServerIP
MWIAnalogLamp
MWIDisplay
StutterToneDuration
EnableMWISubscription
MWIExpirationTime
SubscribeRetryTime
SubscriptionMode
CallerIDType (determines the standard for detection of MWI signals)
ETSIVMWITypeOneStandard
BellcoreVMWITypeOneStandard
VoiceMailInterface
EnableVMURI
8.2.7.8 Caller ID
This section discusses the device's Caller ID support.
8.2.7.8.1 Caller ID Detection / Generation on the Tel Side
By default, generation and detection of Caller ID to the Tel side is disabled. To enable
Caller ID, set the parameter EnableCallerID to 1. When the Caller ID service is enabled:
For FXS: the Caller ID signal is sent to the device's port
For FXO: the Caller ID signal is detected
The configuration for Caller ID is described below:
Use the parameter CallerIDType to define the Caller ID standard. Note that the Caller
ID standard that is used on the PBX or phone must match the standard defined in the
device.
Select the Bellcore caller ID sub standard using the parameter
BellcoreCallerIDTypeOneSubStandard
Select the ETSI FSK caller ID sub standard using the parameter
