Version 6.2 287 February 2011
SIP User's Manual 8. IP Telephony Capabilities
8.3.3 SAS Configuration
SAS supports various configuration possibilities, depending on how the device is deployed
in the network and the network architecture requirements. This section provides step-by-
step procedures on configuring the SAS application, using the device's Web interface.
The SAS configuration includes the following:
General SAS configuration that is common to all SAS deployment types (see ''General
SAS Configuration'' on page 287)
SAS outbound mode (see ''Configuri
ng SAS Outbound Mode'' on page 290)
SAS redundant mode (see
''Configuring SAS Redundant Mode'' on page 291)
Gateway and SAS applications deployed together
(see ''Configuring Gateway
Application with SAS'' on page 291)
Optional, adv
anced SAS features (see ''Advanced SAS Configuration'' on page 295)
8.3.3.1 General SAS Configuration
This section describes the general configuration required for the SAS application. This
configuration is applicable to all SAS modes.
8.3.3.1.1 Enabling the SAS Application
Before you can configure SAS, you need to enable the SAS application on the device.
Once enabled, the device's Web interface provides the SAS pages for configuring SAS.
Note: The SAS application is available only if the device is installed with the SAS
Software Upgrade Key. If your device is not installed with the SAS feature,
contact your AudioCodes representative.
¾ To enable the SAS application:
1. Open the 'Applications Enabling' page (Configuration tab > VoIP menu >
Applications Enabling > Applications Enabling).
2. From the 'Enable SAS' drop-down list, select 'Enable'.
Figure 8-37: Enabling the SAS Application
3. Click Submit.
4. Save the changes to the flash memory with a device reset; after the device resets, the
SAS menu appears and you can now begin configuring the SAS application.
