AudioCodes MediaPack MP-124 User Manual

Version 6.2 207 February 2011
SIP User's Manual 5. EMS-Based Management
5.7 Provisioning SIP MLPP Parameters
This section describes how to configure the MLPP (Multi-Level Precedence and
Preemption) parameters using the EMS.
¾ To configure the MLPP parameters:
1. In the Navigation pane, select VoIP > SIP, and then in the Configuration pane,
select SIP Advanced Configuration; 'SIP Advanced Configuration' frame appears.
2. Select the MLPP tab; the 'MLPP' screen appears.
3. Configure the MLPP parameters as required.
Note: If the following RTP DSCP parameters are set to “-1” (i.e., Not Configured,
Default), the DiffServ value is set with the
PremiumServiceClassMediaDiffserv global gateway parameter, or by using IP
Profiles: MLPPRoutineRTPDSCP, MLPPPriorityRTPDSCP,
MLPPImmediateRTPDSCP, MLPPFlashRTPDSCP,
MLPPFlashOverRTPDSCP, MLPPFlashOverOverRTPDSCP,
MLPPNormalizedServiceDomain.

AudioCodes MediaPack MP-124 Specifications

General

Model	MediaPack MP-124
Category	Gateway
Protocols	SIP, H.323, MGCP
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Fax Support	T.38
Management	SNMP
Security	TLS/SRTP
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25 to 70°C
Humidity	10% to 90%, non-condensing
Analog Ports	24 FXS
