Version 6.2 387 February 2011
SIP User's Manual 10. Configuration Parameters Reference
Parameter Description
stentMode]
dialog\transaction.
[1] = Enable - TCP connections to all destinations are persistent and
not released unless the device reaches 70% of its maximum TCP
resources.
While trying to send a SIP message connection, reuse policy
determines whether live connections to the specific destination are re-
used.
Persistent TCP connection ensures less network traffic due to fewer
setting up and tearing down of TCP connections and reduced latency on
subsequent requests due to avoidance of initial TCP handshake. For
TLS, persistent connection may reduce the number of costly TLS
handshakes to establish security associations, in addition to the initial
TCP connection set up.
Note: If the destination is a Proxy server, the TCP/TLS connection is
persistent regardless of the settings of this parameter.
Web/EMS: TCP Timeout
[SIPTCPTimeout]
Defines the Timer B (INVITE transaction timeout timer) and Timer F
(non-INVITE transaction timeout timer), as defined in RFC 3261, when
the SIP Transport Type is TCP.
The valid range is 0 to 40 sec. The default value is 64*SIPT1Rtx msec.
Web: SIP Destination Port
EMS: Destination Port
[SIPDestinationPort]
SIP destination port for sending initial SIP requests.
The valid range is 1 to 65534. The default port is 5060.
Note: SIP responses are sent to the port specified in the Via header.
Web: Use user=phone in
SIP URL
EMS: Is User Phone
[IsUserPhone]
Determines whether the 'user=phone' string is added to the SIP URI and
SIP To header.
[0] No = 'user=phone' string is not added.
[1] Yes = 'user=phone' string is part of the SIP URI and SIP To
header (default).
Web: Use user=phone in
From Header
EMS: Is User Phone In
From
[IsUserPhoneInFrom]
Determines whether the 'user=phone' string is added to the From and
Contact SIP headers.
[0] No = Doesn't add 'user=phone' string (default).
[1] Yes = 'user=phone' string is part of the From and Contact
headers.
Web: Use Tel URI for
Asserted Identity
[UseTelURIForAssertedI
D]
Determines the format of the URI in the P-Asserted-Identity and P-
Preferred-Identity headers.
[0] Disable = 'sip:' (default)
[1] Enable = 'tel:'
Web: Tel to IP No Answer
Timeout
EMS: IP Alert Timeout
[IPAlertTimeout]
Defines the time (in seconds) that the device waits for a 200 OK
response from the called party (IP side) after sending an INVITE
message. If the timer expires, the call is released.
The valid range is 0 to 3600. The default value is 180.
Web: Enable Remote Party
ID
EMS: Enable RPI Header
[EnableRPIheader]
Enables Remote-Party-Identity headers for calling and called numbers
for Tel-to-IP calls.
[0] Disable (default).
[1] Enable = Remote-Party-Identity headers are generated in SIP
INVITE messages for both called and calling numbers.
