AUTOFLAME Mk8 MM User Manual

3 Commissioning Procedure
Mk8 MM Manual Page | 104
Select the day you want to make changes to the setpoint on, use the black dot in a drag-and-release
motion to set the time periods that you want to define different setpoint for.
By taping on the block dot, it will be activated and appear with green frame indicating that the
setpoint after it can be changed using the setpoint up and down value arrows
Figure 3.9.2.ii: Setting different setpoints throughout the day
To set a variable or gradual setpoint for a specific period of time, tap on the red bar, its colour will change to
blue, specify the start and end setpoints using the up and down arrows.
After setting the setpoint, click to store the settings or click to exit without saving the
changes.
