AUTOFLAME Mk8 MM - Page 170

10 Water Level Control
Mk8 MM Manual Page | 170
6. One capacitance probe, 2
nd
low probe, auxiliary alarm inputs
1
Water level control function
1
3
Capacitance probes
1
5
Auxiliary alarm inputs
1
6
Second low probe
1
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
7. One capacitance probe, auxiliary alarm inputs
1
Water level control function
1
3
Capacitance probes
1
5
Auxiliary alarm inputs
1
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
8. Two capacitance probes
1
Water level control function
1
3
Capacitance probes
2
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
9. Two capacitance probes, auxiliary alarm inputs
1
Water level control function
1
3
Capacitance probes
2
5
Auxiliary alarm inputs
1
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
10. Two capacitance probes, 2
nd
low probe
1
Water level control function
1
3
Capacitance probes
2
6
Second low probe
1
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
11. Two capacitance probes, 2
nd
low probe, auxiliary alarm inputs
1
Water level control function
1
3
Capacitance probes
2
5
Auxiliary alarm inputs
1
6
Second low probe
1
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
12. Two capacitance probes, external level sensor
1
Water level control function
1
3
Capacitance probes
2
4
External level sensor
1
27
Probe mismatch threshold
As required
28
Capacitance probe still water threshold
As required
29
Capacitance probe filter time
As required
30
External level sensor scaling
As required
31
External level sensor filter time
As required
