The table below shows the available Boiler Room Configuration settings:
Setting Default Range Description
1
1
Channel 1 Controls
1
Fuel damper position
2
3
Channel 2 Controls
2
Inlet air damper position
3
Outlet air damper position
7
Rotary cup primary air damper position
3
0
Channel 3 Controls
0
None
2
Inlet air damper position
3
Outlet air damper position
4
FGR air damper position
5
Draught air damper position
6
Steam/air atomisation damper position
7
Rotary cup primary air damper position
4
0
Channel 4 Controls
0
None
2
Inlet air damper position
3
Outlet air damper position
4
FGR air damper position
5
Draught air damper position
6
Steam/air atomisation damper position
7
Rotary cup primary air damper position
5
1
Channel 5 Controls
0
None
1
Burner fan VSD
2
FGR fan VSD
3
Draught fan VSD
4
Rotary cup primary air VSD
6
0
Channel 6 Controls
0
None
1
Burner fan VSD
2
FGR fan VSD
3
Draught fan VSD
4
Rotary cup primary air VSD
7
5
Channel 7 Controls
5
Draught air damper position
