19 Errors & Lockouts
Mk8 MM Manual Page | 381
Exhaust Temperature Absolute
Limit
Exhaust temperature is above absolute limit*
• Alarm or warning depending on option 13
• Check exhaust gas readings and parameter 97
Incorrect/no load sensor detected
• Check option 1
• Check wiring on terminals 37 – 39
3mA or lower received from 4-20mA external modulation/
external setpoint
• Check parameter 69
• Check feedback from external modulation/ external setpoint controller
• Check wiring on terminals 7 – 9
• Warning
• Check mains supply to the MM is within acceptable voltage range
Internal fault in the MM’s main board
•
• Check all fuses on the MM’s main board
• Check the mains supply to the MM is within acceptable voltage range
Internal fault in the MM’s expansion board
• Check all fuses on the MM’s expansion board
• Check the mains supply to the MM is within acceptable voltage range
Oil Pressure Sensor Fault
No comms received from oil pressure sensor
• Warning (lockout 81 if oil pressure limits set in option/parameters 139 and 140)
• Check wiring and screen on terminals 48, 49
Cap Probe 1 Communications
Fault
No comms with capacitance probe 1
• Alarm
• Check wiring and screen on terminals 1P+, 1P-, 1T+ and 1T-
Cap Probe 2 Communications
Fault
No comms with capacitance probe 2
• Alarm
• Check wiring and screen on terminals 2P+, 2P-, 2T+ and 2T-
Cap Probe 1 Short Circuit
Hz reading is below 10kHz
•
• Check water level Hz reading
• Check wiring on terminals 1P+, 1P-, 1T+ and 1T-
Cap Probe 2 Short Circuit
Hz reading is below 10kHz
• Check water level Hz reading
• Check wiring on terminals 2P+, 2P-, 2T+ and 2T-
Cap Probe 1 Temp
Compensation Error
Temperature corrected probe reference is not as expected
• Alarm
• Re-commission capacitance probes at temperature
Cap Probe 2 Temp
Compensation Error
Temperature corrected probe reference is not as expected
• Re-commission capacitance probes at temperature
