AUTOFLAME Mk8 MM User Manual

2 Options & Parameters
Mk8 MM Manual Page | 48
Opt. # Default Range Description
95
0
MM: Input Signal to MM from VSD Channel 5
0
Input range 4 to 20mA
1
Input range 0 to 20mA
2
Input range 0 to 10V
96
0
MM: Input Units Displayed, VSD Channel 5
0
Selected input signal
1
Hertz
97
0
MM: Input Low Speed to MM from VSD Channel 5
0 – 200
Hertz
98
50
MM: Input High Speed to MM from VSD Channel 5
0 – 200
Hertz
99
40
MM: VSD Channel 5 Feedback Fault Tolerance
This is used to check that the feedback varies while modulating. For
example, if this option is set to 4%, the tolerance that is allowed while
firing is ±4% of the whole VSD range. For commissioning, the difference
between the point with the lowest feedback and the point with the highest
feedback must be bigger than twice the tolerance, so for the default of 4%
tolerance, the difference between the point with the lowest feedback and
the point with the highest feedback has to be greater than 8% of the whole
VSD range.
5 – 40
0.5% – 4.0%
100
0
MM: VSD Operation Channel 6
0
Disabled
1
Enabled
101
0
MM: Output from MM to VSD Channel 6
0
Output range 4 to 20mA
1
Output range 0 to 20mA
2
Output range 0 to 10V
102
0
MM: Output Units Displayed, VSD Channel 6
0
Selected output signal
1
Hertz
103
25
MM: Output Low Speed from MM to VSD Channel 6
1 – 200
Hertz
104
50
MM: Output High Speed from MM to VSD Channel 6
1 – 200
Hertz
105
0
MM: Input Signal to MM from VSD Channel 6
0
Input range 4 to 20mA
1
Input range 0 to 20mA
2
Input range 0 to10V
106
0
MM: Input Units Displayed, VSD Channel 6
0
Selected input signal
1
Hertz
107
0
MM: Input Low Speed to MM from VSD Channel 6
0 – 200
Hertz
108
50
MM: Input High Speed to MM from VSD Channel 6
0 – 200
Hertz
