Installation and Upgrades for DEFINITY ONE and
IP600 Internet Protocol Release 10
555-233-109
Issue 6
December 2001
Checklists
viChecklists for Installation Technicians
Install the system cabinet, making sure there is
adequate ventilation.
~ Verify the carrier address ID on RMC
cabinets for most IP600 systems or CMC
cabinets for most Definity One systems.
ID: _________________
~ Mount the cabinets.
For IP600, print a 7” x 11” copy of the
IP600 Mounting Template provided on the
CD.
See ‘‘Install the Avaya IP600
system cabinet’’ on page 1-11
or
‘‘Install the DEFINITY ONE
system cabinet’’ on page 1-56.
Check electrical components.
~ Check AC power.
~ Ground power supply.
~ Connect uninterruptible power supply
(UPS).
~ Disconnect AC power by pulling the AC
power cord from the appliance inlet.
~ Connect cabinet and other grounds.
~ Install coupled bonding connector.
~ Connect the power cords.
See:
‘‘Check AC power and ground
for Avaya IP600I’’ on page
1-19
or
‘‘Check AC power and ground
for DEFINITY ONE’’ on page
1-64.
Connect the cables.
~ Install the processor interface cable.
~ Install the multiple cabinet system cables, if
needed.
See:
‘‘Cable the Avaya IP600
system’’ on page 1-27
or
‘‘Cable the DEFINITY ONE
system’’ on page 1-74.
Install DEFINITY ONE main distribution
frame or RMC patch panels and external
modem.
See either:
DEFINITY Communications
System Generic 1 and Generic
3 Main Distribution Field
Design (555-230-630)
or
‘‘Install DEFINITY ONE main
distribution frame (MDF) and
external modem’’ on page
1-77.
Installation Tasks For More Information
To Next Page
