Installation and Upgrades for DEFINITY ONE and
IP600 Internet Protocol Release 10
555-233-109
Issue 6
December 2001
Checklists
viiChecklists for Installation Technicians
 Install equipment room hardware for Avaya
IP600 or DEFINITY ONE.
~ Cross-connect the cabinet to the patch
panels for IP600 or the MDF for Definity
One.
~ Identify the allowable circuit packs.
~ Install the circuit packs.
~ Make sure that off premises circuits have
protection from hazardous voltages and
currents.
~ Install sneak fuse panels.
~ For Definity One, label the MDF.
See:
DEFINITY Communications
System Generic 1 and Generic
3 Main Distribution Field
Design (555-230-630),
‘‘Install equipment room
hardware for Avaya IP600’’ on
page 1-37
or
‘‘Install equipment room
hardware for DEFINITY
ONE’’ on page 1-80.
 Set ringing option. See ‘‘Set ringing option for
Avaya IP600’’ on page 1-49
or
‘‘Set ringing option for
DEFINITY ONE’’ on page
1-95.
 Install and wire telephones and other
equipment.
~ Install attendant console. (optional)
~ Install 26B1 Console. (optional)
See ‘‘Install and wire
telephones and other
equipment’’ on page 1-97.
 Connect external alarms and auxiliary
connections.
See ‘‘Connect external alarms
and auxiliary connections’’ on
page 1-110.
 Install the BRI terminating resistor. See ‘‘Install the BRI
terminating resistor’’ on page
1-113.
 Use multi-point adapters to provide signal
fanout of the T-interface.
See ‘‘Install multi-point
adapters’’ on page 1-117.
 Wire the off-premises stations with the cabling
provided by the local telephone company.
See ‘‘Install off-premises
station wiring’’ on page 1-120.
 Install the emergency transfer panel (or
equivalent) and associated analog telephones
to provide emergency transfer capabilities.
See ‘‘Install emergency
transfer panel and associated
telephones’’ on page 1-125.
 Connect modem. See ‘‘Connect modem to
telephone network’’ on page
1-133 and ‘‘Connect modem’’
on page 1-134.
Installation Tasks For More Information
To Next Page
