13.4.2.1 A OPX SETUP / A OP1/2/3 Dividing factor PINs 251 / 254 / 257
This factor is normally set to provide a maximum amplitude of 10 V for the terminal signal voltage. The PL/X
default 100.00 % voltage is 10.00V. Hence a dividing factor of 1.000 gives 10.00 V amplitude for 100.00 %
signals. This factor is arranged as a divider function to allow high gains if required, by dividing by numbers
less than 1.0000. This scaling takes place prior to the addition of an offset in the next windo w.
13.4.2.2 A OPX SETUP / A OP1/2/3 Offset PINs 252 / 255 / 258
Note 100.0 0% is equivalent to 10.00 V. Changing the divider factor will not affect the offset value.
13.4.2.3 A OPX SETUP / A OP1/2/3 Rectify mode enable PINs 253 / 256 / 259
13.4.2.4 A OPX SETUP / A OP1/2/3 Make output GET FROM source connection
13.4.2.5 Default connections for A OP1/2/3
A OPX Function Terminal GET FRO M
A OP1 Unfiltered total speed feedback T1 0 PIN 715
A OP2 Unfiltered total speed reference T11 PIN 123
A OP3 Unfiltered armature current demand T12 PIN 718
Note. The function 260)SC OPE OP SELEC T described belo w uses A OP3. Any internal GETFROM connection
made to A OP3 is left intact but ignored by 260)SCOPE OP SELECT function.
A OP1 (T1 0) SETUP 4
251)A OP1 DIVIDER
251)A OP1 DIVIDER
+ 1.0000
PARA METER RA NGE DEF AULT PIN
A OP1 DIVIDER + /- 3.0000 + 1.0000 251
Divides the GET FROM signal
source by a signed factor.
A OP1 (T1 0) SETUP 4
252)A OP1 OFFSET
252)A OP1 OFFSET
0.00%
PARA METER RA NGE DEFAULT PIN
A OP1 OFFSET + /- 100.00 % 0.00% 252
Sets the level of bi-polar offset
to be added to the final signal.
A OP1 (T1 0) SETUP 4
253)A OP1 RECTIFY EN
253)A OP1 RECTIFY EN
DISABLED
PARA METER RA NGE DEF AULT PIN
A OP1 REC TIFY EN EN ABLED or DISABLED DIS ABLED 253
Allo ws the output mode to be
rectified when enabled.
A OP1 (T1 0) SETUP 4
GET FROM
GET FROM
PIN) Description of function
PARA METER RA NGE DEF AULT
GET FROM PIN 000 to 720 See 13.4.2.5
Defines the source PIN for the
connection to A OPX.
