PIN number tables 221
15.1.2 Diagnostics and alarms 123 - 183
Property Paragraph Menu / Description Range Default PIN
R 7.1.1 SPEED LOOP MONITOR / Total speed reference monitor PIN 123 + /-300.00% 0.00 % 1 23
7.1.2 SPEED LO OP M ONIT OR / Speed demand monitor PIN 124 + /-300.00% 0.00 % 1 24
7.1.3 SPEED LO OP M ONIT OR / Speed error monitor PIN 125 + /-300.00% 0.00 % 125
R 7.1.4 SPEED LOOP MONITOR / Armature volts monitor PIN 126 + /-125 0.0V 0.0 V 126
7.1.5 SPEED LO OP M O NIT OR / Armature volts % monitor PIN 127 + /-300.00 % 0.00% 12 7
7.1.6 SPEED LO OP M ONIT OR / Back emf % monitor PIN 12 8 + /-300.00 % 0.00% 128
R 7.1.7 SPEED LO OP M ONIT OR / Tachogenerator volts monitor PIN 129 + /-220.00 V 0.00 V 1 29
R 7.1.8 SPEED LO OP M O NIT OR / Motor RPM monitor PIN 13 0 + /- 7500 rpm 0 rpm 1 30
R 7.1.10 SPEED LOOP MONITOR / Speed feedback % monitor PIN 131 + /-300.00 % 0.00% 131
R 7.1.9 SPEED LO OP M O NIT OR / Encoder RPM monitor PIN 132 + /- 7500 rpm 0 rpm 132
R 7.2.1 ARM I LOOP M O NITOR / Arm current demand monitor PIN 133 + /- 150.00% 0.00 % 133
R 7.2.2 ARM I LOOP M O NITOR / Arm current % monitor PIN 134 + /- 150.00% 0.0 0 % 134
R 7.2.3 ARM I LOOP M O NITOR / Arm current amps monitor PIN 135 + /-3000.0 A 0.00 Amps 135
7.2.4 ARM I LO OP MONITOR / Upper current limit monitor PIN 136 + /-150.00% 0.00 % 1 36
7.2.5 ARM I LO OP MONITOR / Lower current limit monitor PIN 137 + /-150.00% 0.00 % 13 7
R 7.2.6 ARM I LOOP MONITOR / A ctual upper limit monitor PIN 13 8 + /-150.00% 0.00 % 1 38
R 7.2.6 ARM I LOOP M O NITOR / Actual lower limit monitor PIN 1 39 + /-150.00% 0.00 % 139
7.2.7 ARM I LO OP MONITOR / Overload limit monitor PIN 140 0 -1 50.00 % 0.00% 140
7.2.8 ARM I LO OP MONITOR / A t current limit flag PIN 14 1 0 - 1 Lo w 141
0 142
R 7.3.1 FIELD MONITOR / Field demand monitor PIN 143 0 -100.00% 0.00% 143
R 7.3.2 FIELD MONITOR / Field current % monitor PIN 144 0 -1 25.00 % 0.00% 144
R 7.3.3 FIELD MONITOR / Field amps monitor PIN 14 5 0 – 50.00 A 0.00 Amps 145
7.3.4 FIELD MONITOR / Field firing angle monitor PIN 14 6 0 – 155 Deg 0 Deg 146
7.3.5 FIELD M ONITOR / Field active monitor PIN 147 0 - 1 disabled 147
0 148
0 149
R 7.4.1 A N ALOG IO MONIT OR / UIP2 analogue input monitor PIN 15 0 + /- 30.730 0.000 V 150
R 7.4.1 A N ALOG IO MONIT OR / UIP3 analogue input monitor PIN 15 1 + /- 30.730 0.000 V 151
R 7.4.1 A N ALOG IO MONIT OR / UIP4 analogue input monitor PIN 15 2 + /- 30.730 0.000 V 152
7.4.1 A NALO G IO MONITOR / UIP5 analogue input monitor PIN 153 + /- 30.7 30 0.000 V 153
7.4.1 A NALO G IO MONITOR / UIP6 analogue input monitor PIN 154 + /- 30.7 30 0.000 V 154
7.4.1 A NALO G IO MONITOR / UIP7 analogue input monitor PIN 155 + /- 30.7 30 0.000 V 155
7.4.1 A NALO G IO MONITOR / UIP8 analogue input monitor PIN 156 + /- 30.7 30 0.000 V 156
7.4.1 A NALO G IO MONITOR / UIP9 analogue input monitor PIN 157 + /- 30.7 30 0.000 V 157
0 158
7.4.2 A NALO G IO MONIT OR / A OP1 analogue output monitor PIN 159 + /-11.300 V 0.000 V 159
7.4.2 A NALO G IO MONIT OR / A OP2 analogue output monitor PIN 160 + /-11.300 V 0.000 V 160
7.4.2 A NALO G IO MONIT OR / A OP3 analogue output monitor PIN 161 + /-11.300 V 0.000 V 161
R 7.5.1 DIGIT AL IO MONIT OR / UIP2 to 9 digital input monitor PIN 1 62 0/1 times 8 00000000 1 62
R 7.5.2 DIGIT AL IO MONIT OR / DIP1-4 and DIO 1-4 dig IP monitor PIN 163 0/1 times 8 00000000 163
R 7.5.3 DIGIT AL IO MONIT OR / DOP1-3 + Control IPs dig OP mon PIN 164 0/1 times 8 000 00000 1 64
7.5.4 DIGITAL IO MONIT OR / + Armature bridge flag PIN 165 0 - 1 Low 16 5
R 7.5.5 DIGIT AL IO MONIT OR / Drive start flag PIN 1 66 0 - 1 Low 1 66
R 7.5.6 DIGIT AL IO MONIT OR / Drive run flag PIN 167 0 - 1 Low 167
R 7.5.7 DIGITAL IO MONIT OR / Internal running mode monitor PIN 1 68 1 of 8 modes Stop 16 8
R 7.7 DIA GNOSTICS / EL1/2/3 RMS monitor PIN 16 9 0- 1000.0 V 0.0 V 169
R 7.8 DIA GNOSTICS / DC KILO WA T TS monitor PIN 169 + /-3000.0Kw 0.0 170
R 8.1.1 M O T OR DRIVE ALARMS / Speed fb mismatch trip enable PIN 1 71 0 - 1 Enabled 171
8.1.2 MOTOR DRIVE ALARMS / Speed fb mismatch tolerance PIN 172 0 -100.00% 50.00 % 17 2
R 8.1.3 M O T OR DRIVE ALARMS / Field loss trip disable PIN 173 0 - 1 Enabled 173
8.1.4 MOTOR DRIVE ALARMS / Dig OP short circuit trip enable PIN 174 0 - 1 Disabled 174
8.1.5 MOTOR DRIVE ALARMS / Missing pulse trip enable PIN 17 5 0 - 1 Enabled 175
8.1.6 MOTOR DRIVE ALARMS / Reference exhange trip enable PIN 176 0 - 1 Disabled 176
8.1.7 MOTOR DRIVE ALARMS / Overspeed delay time PIN 1 77 0.1 – 600.0 s 5.00 secs 177
R 8.1.8.1 STALL TRIP MENU / Stall trip enable PIN 1 78 0 - 1 Enabled 178
R 8.1.8.2 STALL TRIP MENU / Stall current level PIN 179 0 -150.00% 9 5.00% 179
R 8.1.8.3 STALL TRIP MENU / Stall delay time PIN 180 0.1 – 600.0 s 10.0 secs 180
8.1.9 MOTOR DRIVE ALARMS / A ctive trip monitor PIN 1 81 0000 - FFFF 0000 181
8.1.9 MOTOR DRIVE ALARMS / Stored trip monitor PIN 182 0000 - FFFF 0 182
8.1.10 MOTOR DRIVE ALARMS / External trip reset enable PIN 183 0 - 1 Enabled 18 3
