222 PIN number tables
15.1.3 Serial links 187 - 249
Property Paragraph Menu / Description Range Default PIN
0 184
0 185
0 186
R 10.1.2 RS232 PORT 1 / Port1 Baud rate PIN 1 87 300 - 57600 9600 1 87
S 10.1.3 PORT1 FUNCTION / Port1 function mode PIN 188 1 of 4 modes Param exch 188
10.3.1 PORT1 REF EXCHANGE / Ref exchange slave ratio PIN 189 + /-3.0000 1.000 0 189
10.3.2 PORT1 REF EX CH ANGE / Ref exchange slave sign PIN 1 90 0 - 1 Non-invert 1 90
10.3.3 PORT1 REF EXCHANGE / Ref exchange slave monitor PIN 191 + /-300.00 % 0.00% 19 1
10.3.4 PORT1 REF EXCHANGE / Ref exchange master monitor PIN 1 92 + /-300.0 0 % 0.00% 192
10.2.5 PORT 1 COMMS LINK / Port 1 group ID PIN 193 0 - 7 0 193
10.2.5 PORT 1 COMMS LINK / Port 1 unit ID PIN 194 0 - 15 0 194
10.2.5 PORT 1 COMMS LINK / Port 1 error code PIN 195 1 - 8 1 195
S 10.2.5 PORT 1 COMMS LINK / Port 1 DOP3 RTS mode PIN 196 0 - 1 Disabled 196
197
198
FIELDBUS CONFIG / Fieldbus data control PIN 19 9 00 - 11 00 199
Serial
Comms
FBUS ON-LINE MON (Hidden pin) 0 - 1 Lo w 200
201
202
RESERV ED 203
to
239
6.10.9.3 SPINDLE ORIENT ATE / Marker enable PIN 240 0 - 1 Disabled 240
6.10.9.4 SPINDLE ORIENT A TE / Marker offset PIN 241 + /-15,0 00 0 241
6.10.9.5 SPINDLE ORIENT A TE / Position reference PIN 242 + /-30,000 0 242
6.10.9.6 SPINDLE ORIENT ATE / Marker frequency monitor PIN 243 20-655.37 Hz 0 Hz 243
6.10.9.7 SPINDLE ORIENT ATE / In position flag PIN 2 44 0 - 1 Low 244
15.1.4 Configuration 251 - 400
Property Paragraph Menu / Description Range Default PIN
13.4.1 A NALOG OUTPUTS / Iarm o/p rectify enable PIN 250 0 - 1 Disabled 250
13.4.2.1 A OP1 (T10) SETUP / A OP1 Dividing factor PIN 2 51 + /- 3.0000 1.0000 251
13.4.2.2 A OP1 (T10) SETUP / A OP1 Offset PIN 252 + /-100.0 0 % 0.00 % 252
13.4.2.3 A OP1 (T10) SETUP / A OP1 Rectifier mode enable PIN 25 3 0 - 1 Disabled 25 3
13.4.2.1 A OP2 (T11) SETUP / A OP2 Dividing factor PIN 2 54 + /- 3.0000 1.0000 254
13.4.2.2 A OP2 (T11) SETUP / A OP2 Offset PIN 255 + /-100.0 0 % 0.00 % 255
13.4.2.3 A OP2 (T11) SETUP / A OP2 Rectifier mode enable PIN 25 6 0 - 1 Disabled 25 6
13.4.2.1 A OP3 (T12) SETUP / A OP3 Dividing factor PIN 2 57 + /- 3.0000 1.0000 257
13.4.2.2 A OP3 (T12) SETUP / A OP3 Offset PIN 258 + /-100.0 0 % 0.00 % 258
13.4.2.3 A OP3 (T13) SETUP / A OP3 Rectifier mode enable PIN 25 9 0 - 1 Disabled 25 9
13.4.3 A NALOG OUTPUTS / Scope output select on A OP3 PIN 260 0 - 1 Disabled 260
13.7.1.1 D OP1 (T22) SETUP / DOP1 Output value rectifier enable PIN 261 0 - 1 Enabled 261
13.7.1.2 D OP1 (T22) SETUP / DOP1 OP comparator threshold . PIN 262 + /-300.0 0 % 0.00 % 262
13.7.1.3 D OP1 (T22) SETUP / DOP1 Output inversion mode PIN 26 3 0 - 1 Non invert 263
13.7.1.1 D OP2 (T23) SETUP / DOP2 Output value rectifier enable PIN 264 0 - 1 Enabled 264
13.7.1.2 D OP2 (T23) SETUP / DOP2 OP comparator threshold PIN 26 5 + /-300.0 0 % 0.0 0 % 265
13.7.1.3 D OP2 (T23) SETUP / DOP2 Output inversion mode PIN 26 6 0 - 1 Non invert 266
13.7.1.1 D OP3 (T24) SETUP / DOP3 Output value rectifier enable PIN 267 0 - 1 Enabled 267
13.7.1.2 D OP3 (T24) SETUP / DOP3 OP comparator threshold PIN 26 8 + /-300.0 0 % 0.0 0 % 268
13.7.1.3 D OP3 (T24) SETUP / DOP3 Output inversion mode PIN 26 9 0 - 1 Non invert 269
0 270
S 13.6.1.1 DIO 1 (T18) SETUP / DIO 1 Output mode enable PIN 27 1 0 - 1 Disabled 271
13.6.1.2 DIO 1 (T18) SETUP / DIO 1 Output value rectify enable PIN 272 0 - 1 Enabled 272
13.6.1.3 DIO 1 (T18) SETUP / DIO 1 OP comparator threshold PIN 273 + /-300.0 0 % 0.0 0 % 273
13.6.1.4 DIO 1 (T18) SETUP / DIO 1 Output inversion mode PIN 274 0 - 1 Non invert 274
13.6.1.7 DIO 1 (T18) SETUP / DIO 1 Input high value PIN 2 75 + /-300.00 % 0.01 % 275
13.6.1.8 DIO 1 (T18) SETUP / DIO 1 Input lo w value PIN 276 + /-300.00% 0.00% 276
S 13.6.1.1 DIO 2 (T19) SETUP / DIO 2 Output mode enable PIN 27 7 0 - 1 Disabled 277
13.6.1.2 DIO 2 (T19) SETUP / DIO 2 Output value rectify enable PIN 278 0 - 1 Enabled 278
13.6.1.3 DIO 2 (T19) SETUP / DIO 2 OP comparator threshold PIN 279 + /-300.0 0 % 0.0 0 % 279
13.6.1.4 DIO 2 (T19) SETUP / DIO 2 Output inversion mode PIN 28 0 0 - 1 Non invert 280
13.6.1.7 DIO 2 (T19) SETUP / DIO 2 Input high value PIN 2 81 + /-300.00 % 0.01 % 281
13.6.1.8 DIO 2 (T19) SETUP / DIO 2 Input lo w value PIN 282 + /-300.00% 0.00% 282
