Chapter 2: Pre-installation Guide:
Unpacking & placing of GENIUS Compact optical sorter
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 ©
BESTnv
Pulsarr Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.pulsarr@bestnv.com
2.2. Machine parts
The machinery will normally be loaded directly on the truck. It may be packed in crates depending on
the mode of transport (by boat). Certain additional parts and spare parts may be sent along with the
GENIUS Compact sorter unit.
Table 2.1a: GENIUS Compact 640
Machine Part
max. Dimensions (mm/inch)
Weight (kg/lbs)
Length Width Height
GENIUS C unit 3345 (131.7) 1279 (50.4) 2317 (91.2) max. 1800 (4000)
Infeed Shaker 1800 (70.9) 650 (25.5) 1268 (50) max. 750 (1650)
Table 2.1b: GENIUS Compact 1200
Machine Part
max. Dimensions (mm/inch)
Weight (kg/lbs)
Length Width Height
GENIUS C unit 3345 (131.7) 1930 (76) 2317 (91.2) max. 2200 (4850)
Infeed Shaker 1800 (70.9) 1300 (51) 1268 (50) max. 1000 (2200)
List of parts on the crates:
1 GENIUS Compact optical sorter + 4 Adjustable Feet
1 Infeed Shaker + 4 Adjustable Feet
1 Accept Shaker/Belt (sometimes mounted on sorter frame) Optional
1 Reject Shaker/Belt (sometimes mounted on sorter frame) Optional
Return system (shakers/belts for DRS or ARS system) Optional
1 Set of door keys
Background Drums (if necessary) Optional
2 GENIUS Compact Manuals
1 Standard Spare Parts Box (see list below) Optional
List of standard spare parts (recommended):
1 Power Supply Astec MVP1, 100V - 240V, 15A
1 Power Supply Astec MVP4, 100V - 240V, 7A
1 Power Supply Omron S82K - 10024, DC 24V, 0.1A - 4.2A
1 Airco Filter
4 Air Gun Valves
