Chapter 7: Maintenance
7/10
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 © BESTnv
BESTnv Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.BESTnv@bestnv.com
12
4
3
5
3
1. Loosen bolt to release bearing block supports.
2. Remove safety plate of belt drive drum (remove 2 bolts).
3. Unscrew bolts and open wedges.
7.5.2. Replacing the Detection Belt
The Detection Belt has to be replaced regularly (exact frequency depends on product and machine
confi guration). Make sure to have the necessary tools available (spanners/wrenches).
Belt Replacement Procedure:
