Chapter 2: Pre-installation Guide:
Unpacking & placing of GENIUS Compact optical sorter
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 ©
BESTnv
Pulsarr Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.pulsarr@bestnv.com
Picture 2.5.2: Total installation schedule
Feeding of
Feeding of
infeed
infeed
shaker
shaker
Nitrogen
tubing
BY PURCHASER
OPTIONAL
Compressed
air supply
Warm water
Handling of
Handling of
the accepted
the accepted
product
product
Nitrogen
Cold water
Handling of
Handling of
the reject
the reject
Electricity
supply sorter
Electricity
supply cooling
Cooling unit
MTA TAE
M010 / 020
Infeed shaker
C
C
B
B
A
A
2.5.2. The GENIUS Compact optical sorter
Mechanical mounting of the GENIUS Compact optical sorter installation
The Purchaser will take care of the mechanical installation of the GENIUS Compact optical sorter in
the area agreed upon. To this end he will provide all necessary and appropriate lifting, hoisting and
transporting devices.
A: Connections to Belt motor & Shaker motors (usually on same side as belt motor).
B: Water connection belt cleaning system
C: Water connection cleaning system bottom unit (option) underneath sorter
